A213 T5 T9 Alloy Heat-Exchanger Steel Tubes
ASTM A213 is a standard specification for seamless ferritic and austenitic alloy-steel boiler, superheater, and heat-exchanger tubes.
ASTM A192 Referenced Documents:
ASTM A450 / A450M Specification for General Requirements for Carbon, Ferritic Alloy, and Austenitic Alloy Steel Tubes.
Standard: ASTM A192 / ASME SA 192
Description Name: ASME SA 192 / ASTM A192 boiler pipes; A192 pipes; A192 carbon steel tube; ASTM A192 seamless tubing; ASTM A192 carbon steel pipe; SA192 SEAMLESS PIPE; ASTM A192 cold drawn seamless steel tubes; ASTM A192 pipes and tubing; carbon steel tube; Seamless steel tube; steel tube.
Size: 1⁄2 in. to 12 in. [12.7 to 304.8 mm]
Schedule: 1.5mm-35mm
Shape: Round
Production type: Hot finished and cold finished.
Length: Single random length/ Double random length or as customer's actual request max length is 27m.
Grade: A192 / SA192
| Seamless, Cold-Finished Tubes | ||
| Outside Diameter
In. (mm) |
Wall thickness Tolerance % | |
| Over (+) | Under (-) | |
| 1 ½ (38.1) and under | 20 | 0 |
| Over 1½ (38.1) | 22 | 0 |
| Cold-Finished Seamless Tubes | ||
| Outside Diameter
In. (mm) |
Permissible Variations In. (mm) | |
| Over (+) | Under (-) | |
| Under 1 (25.4) | 0.004 (0.1) | 0.004 (0.1) |
| 1 to 1 ½ (25.4 to 38.1), Incl | 0.006 (0.15) | 0.006 (0.15) |
| Over 11⁄2 to 2 [38.1 to 50.8], Excl | 0.008 (0.2) | 0.008 (0.2) |
| 2 to 21⁄2 [50.8 to 63.5], Excl | 0.010 (0.25) | 0.010 (0.25) |
| 21⁄2 to 3 [63.5 to 76.2], Excl | 0.012 (0.3) | 0.012 (0.3) |
ASTM A192 Seamless Tubes Flattening Test
One flattening test shall be made on specimens from each end of two tubes selected from each lot or fraction thereof.
ASTM A192 Seamless Tubes Flaring Test
One flaring test shall be made on specie- men from each end of two tubes selected from each lot or fraction thereof. These tubes shall be selected apart from those used for the flattening test.
