API 5CT C90 Casing Tubing serves to transport both crude oil and natural gas from oil and gas layer to the surface pipeline after drilling is completed. It is able to bear the pressure produced by the exploitation process. After the outer surface is coated with a protective layer, the tubing is marked in accordance with the API 5CT standard and strapped with metal belt.
Available Sizes: 2 3/8″, 2 7/8″ and 3 ½” Outer Diameter
Grades: J55, J55-FBNAU, N80, L80, P110
Product Introduction
Technical data
Related Products
Service
Related Projects
Inquiry
Product Introduction
API 5CT C90 Casing Tubing is a API 5CT Oil Casing Pipe & mainly used for oil well drilling. We manufacture API 5CT C90 Casing Tubing in accordance with the SY/T6194-96 standard, it is available as short thread type and long thread type supplied with their couplings.

According to American Petroleum Institute Standard API SPEC 5CT1988 1st edition, the steel grade of API 5CT oil casing pipe can be divided into ten types, including H-40, J-55, K-55, N-80, C-75, L-80, C-90, C-95, P-110 and Q-125. We supply the casing pipe & API 5CT C90 Casing Tubing accompanied with thread and coupling, or we offer our product in accordance with the following forms for option.

If you are interested in API 5CT C90 Casing Tubing, we will supply you with the best price based on the highest quality.
Technical data

C90 Casing Tubing Dimensions

Pipe Casing Sizes, Oilfield Casing Sizes & Casing Drift Sizes
Outer Diameter (Casing Pipe Sizes) 4 1/2"-20", (114.3-508mm)
Standard Casing Sizes 4 1/2"-20", (114.3-508mm)
Thread Type Buttress thread casing, Long round thread casing, Short round thread casing
Function It can protect the tubing pipe.


Oil Tube For Petroleum And Natural Gas Industries

Name of Pipes

Specification Steel Grade Standard
  D (S) (L)
(mm) (mm) (m)
Petroleum Casing Pipe 127-508 5.21-16.66 6-12 J55. M55. K55.
L80. N80. P110.
API Spec 5CT (8)
Petroleum Tubing 26.7-114.3 2.87-16.00 6-12 J55. M55. K55.
L80. N80. P110.
API Spec 5CT (8)
Coupling 127-533.4 12.5-15 6-12 J55. M55. K55.
L80. N80. P110.
API Spec 5CT (8)


API 5CT Gr. C90 Tubing Chemical Composition

  C Mn Mo Cr Ni Cu Ti P S Si V Al
Min - - 0.250 - - - - - - - - -
Max 0.350 1.200 0.850 1.500 0.990 - - 0.020 0.010 - - -


API 5CT C90 Casing Tubing Features

Grade C90 Oil Well Drilling Tube in different shapes and sizes available.


API 5CT C90 Mechanical Properties

Tensile Strength 689 MPa min 100,000 psi min
Yield Strength 621 MPa min 724 MPa max
  90,000 psi min 105,000 psi max
Total Elongation Under Load 0.500 % -
Hardness 25 Max HRC 255 Max HBW


API 5CT Grade C90 Casing Tubing Steel Color CodeBest High-quality API 5CT Gr. C90-1 Oil Tubing supplierss & dealer of Api c90 Seamless 5ct Petroleum Casing Pipe.

Name J55 K55 N80-1 N80-Q L80-1 P110
Casing a bright green band two bright green bands a bright red band a bright red band + a green band a red band + a brown band a bright white band
Coupling entire green coupling + a white band entire green coupling entire red coupling entire red coupling + a green band entire red coupling + a brown band entire white coupling
