We can help supply all of the Carbon Steel API 5L EFW Pipe Tube or linepipe supplies that your company needs for use in the oil or natural gas industries.
Types:Seamless / ERW / Welded / Fabricated / LSAW Pipes
Form:Round, Square, Rectangular, Coil, U Tube
Product Introduction
Related Products
Service
Related Projects
Inquiry
Product Introduction
GNEE Steel is one of the largest API 5L EFW Pipes Manufacturer & Exporter, Which are available in various grades and dimensions as per the requirements of our valued customers. Our manufacturing team makes sure to follow all the national and international quality standards while fabricating Carbon Steel API 5L EFW Pipes. These specifications standardize pipeline transportation systems within the equipment, materials, and offshore structures for petroleum, petrochemical industries, and natural gas. We design premium quality API 5L EFW Pipes having high yield strength, which we can modify as per the offshore structural purposes.

GNEE Steel has been known for exporting API 5L EFW Pipes worldwide. API 5L EFW Pipes have been used in different industries such as the oil and gas industry for their high strength. Our API 5L EFW Pipes are made with precision and the highest quality of raw material to provide maximum output at a low cost. We provide all types of API 5L EFW Pipes that include Grades: API 5L GR. B, X42, X52, X56, X60, X65, X70, X100 Pipes. We supply premium quality API 5L Seamless Pipes.


API 5L EFW Pipes Specification & Standard

API 5L Specification For Line Pipe API 5L, ASTM A1024 / A1024M, ISO 3183
API 5L EFW Pipe Standard API 5L (Specification for Line Pipe – ANSI/API specification 5L – 44th Edition, October 1, 2007)
Hot rolled API 5L EFW pipe upto 20 inch (508 mm)
API 5L EFW Pipe (hot expanding processes) : upto 40 inch 1016 mm.
API 5L Pipe Sizes Nominal API 5L Line Pipe Sizes 1/2″ to 48 ” O.D.
Wall Thickness – Schedule 10 through 160, STD, XS, XXS.
Product Specification Level (PSL) for API Line Pipes API 5L PSL 2
API 5L PSL 1
Origin of API 5L Line Pipe Japanese Origin, Korean Origin, European Origin, US Origin, Ukraine Origin, Russian Origin
API 5L Pipe Value added service
  • Fusion Bond Epoxy
  • ARO
  • 3LPE
  • Heat Treatment
  • Bending
  • Galvanizing
  • Tar Epoxy
  • Annealed
  • Sand Blasting
  • Draw & Expansion as per required Size & Length
  • Machining etc.
API 5L Line Pipe Thickness SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XS, SCH XXS, All Schedules in API 5L Pipes
API 5L Carbon Steel Pipe Applications Oil Refineries, Petrochemicals, Steel, Sugar, Boiler Equipments, Pressure Vessels, Power Generation (Nuclear/Thermal) and General Engineering Purposes
HIC Tested Carbon Steel Line Pipe End Screwed, Plain, Bevel, Threaded
API 5L Pipes Type EFW / EFW / ERW / Welded / Fabricated / CDW / PSL1 / PSL2 Pipe
API Line Pipe Length Single Random, Double Random & Required Length, Custom Size – 12 Meter lengths
Testing and Third Party Inspection available EN 10204 3.1, PMI Test Reports, Visual Inspection Reports, Destructive Test Report, Non Destructive Test Reports, Mill TC EN 10204 3.1, NABL Approved Lab, Chemical and Mechanical Reports, Third Party Inspection Reports, India Boiler Regulations (IBR) Test Certificate
API 5L Pipes Packing API 5L GR. B Pipe Packed in Steel Strips Bundled, Wooden Boxes, Plastic Bags, or as per Customers Requests
API 5L Pipes Finishes Galv, FBE, FBE Dual, 3LPE, Bare, Oiled, Mill Varnish, 3LPP, Coal Tar, Concrete Coating and Tape Wrap.
End Finishes of API 5L Line Pipe: Beveled, Square Cut, Threaded & Coupled.
Application & uses of PSL1 & PSL2 Pipe
  • API 5L Line pipe are suitable for Conveying gas, water, oil, and other liquefied media.
  • Large diameter API 5L Pipe for high pressure gas transportation
  • Thick wall API 5L Pipe for submarine pipeline
  • Suitable for sour services and in H2S environment
Other manufacturers of API EFW steel pipe MSL, JSL, ISMT, USL, BAO, Lontrin, SMTM, TNRS, V&M and Wuxi
API 5L EFW Pipe Scope API 5L Carbon Steel EFW Pipe covers API 5L PSL1 and API 5L PSL2 suitable for use in conveying gas, water, and oil in both the oil and natural gas industries.
Hot-Dipped Galvanizing May be ordered galvanized.
Kinds of Steel Permitted For API 5L Pipe Material Electric-furnace
Open-hearth
Basic-oxygen
Manufacturing techniques for API 5L EFW Pipe API 5L Welded Pipe



  • API 5L Spiral submerged arc welded pipe (SSAW)
  • API 5L Straight seam submerged arc welding pipe (LSAW)
  • API 5L Resistance welded pipe (ERW)

API 5L EFW Pipe
API 5L SAW Pipe
ERW Line Pipe

BS EN 10208-2:2009 Standard for pipelines for combustible fluids. Technical delivery conditions. Pipes of requirement class B. Suitable to use in maximum operating pressure over 16 bar.
Test Methods applicable on API 5L Line Pipe
  • Bend test
  • Hydrostatic test
  • Flattening test
  • Guided-bend test
  • CVN impact test for API 5L PSL2 pipe (including pipe body tests, pipe weld and HAZ tests)
  • DWT test for API 5L PSL2 welded pipe


API 5L EFW Pipes and Welded Pipes Size Chart

NPS OD Wall Thickness
STD Sch40 XS Sch80 Sch160 XXS
1/8″ 10.3 1.73 1.73 2.41 2.41
1/4″ 13.7 2.24 2.24 3.02 3.02
3/8″ 17.1 2.31 2.31 3.2 3.20
1/2″ 21.3 2.77 2.77 3.73 3.73 4.78 7.47
3/4″ 26.7 2.87 2.87 3.91 3.91 5.56 7.82
1″ 33.4 3.38 3.38 4.55 4.55 6.35 9.09
1 1/4″ 42.2 3.56 3.56 4.85 4.85 6.35 9.7
1 1/2″ 48.3 3.68 3.68 5.08 5.08 7.14 10.16
2″ 60.3 3.91 3.91 5.54 5.54 8.74 11.07
2 1/2″ 73 5.16 5.16 7.01 7.01 9.53 14.02
3″ 88.9 5.49 5.49 7.62 7.62 11.13 15.24
3 1/2″ 101.6 5.74 5.74 8.08 8.08
4″ 114.3 6.02 6.02 8.58 8.56 13.49 17.12
5″ 141.3 6.55 6.55 9.53 9.53 15.88 19.05
6″ 168.3 7.11 7.11 10.97 10.97 18.28 21.95
8″ 219.1 8.18 8.18 12.7 12.70 23.01 22.23
10″ 273 9.27 9.27 12.7 15.09 28.58 25.4
12″ 323.8 9.53 10.31 12.7 17.48 33.32 25.4
14″ 355.6 9.53 11.13 12.7 19.05 35.71
16″ 406.4 9.53 12.7 12.7 21.44 40.4
20″ 508 9.53 15.09 12.7 26.18 50.01
24″ 610 9.53 17.48 12.7 30.96 59.54


APL 5L EFW Pipes Applications and Uses

Heat Exchangers
Condensers
Pulp and Paper Industry
Off-Shore Oil Drilling Companies
Power Generation
Petrochemicals
Gas Processing
Specialty Chemicals
Pharmaceuticals
Pharmaceutical Equipment
Chemical Equipment
Sea Water Equipment
Packing, and delivery
APL 5L EFW Pipes price, packing, and delivery:
APL 5L EFW Pipes Payment Modes: LC (Letter of Credit), TT (Telegraphic Transfer or Wire Transfer), Cheque and others.
APL 5L EFW Pipes Packaging: APL 5L EFW Pipes are packaged with caution and safety so they reach our client’s as good as he would expect.
Packaging Charges Extra.
