DIN17175 12CrMo195 Seamless Alloy Pipe
DIN17175 12CrMo195 Seamless Alloy Pipe
DIN17175 12CrMo195 Seamless Alloy Pipe
DIN17175 12CrMo195 Seamless Alloy Pipe
DIN17175 12CrMo195 Seamless Alloy Pipe
DIN17175 12CrMo195 Seamless Alloy Pipe
DIN17175 12CrMo195 Seamless Alloy Pipe
DIN17175 12CrMo195 Seamless Alloy Pipe

DIN17175 12CrMo195 Seamless Alloy Pipe

DIN 17175 12CrMo195 is a specification that covers seamless tubes of heat-resistant steels. The material 12CrMo195 is a low-alloy steel commonly used for high-temperature applications.
standard:DIN
Surface :1. Galvanized 2. Black and Color Painting
introduction
Technical Data
Related Products
Service
Related Projects
Inquiry
introduction
DIN 17175 12CrMo195 is a low alloy steel pipe widely used in high temperature environments. Its chemical composition includes carbon, manganese, silicon, phosphorus, sulfur, chromium and molybdenum, of which carbon (C): 0.08-0.15%,Manganese (Mn): 0.40-0.65% ,Silicon (Si): 0.10-0.35% ,Phosphorus (P): Max 0.025% ,Sulfur (S): Max 0.020% ,Chromium (Cr): 0.90-1.20% ,Molybdenum (Mo): 0.15- 0.25% ,This material has excellent mechanical properties. After appropriate heat treatment, its tensile strength, yield strength, elongation and hardness can meet the requirements of high temperature applications. Tensile strength: 410-530 MPa Yield strength: minimum 255 MPa Elongation: minimum 21% Hardness: ≤197HB.
In high temperature applications, DIN 17175 12CrMo195 seamless alloy pipe is mainly used to transport steam, superheated steam and other high temperature fluids in facilities such as power plants, boilers and petrochemical plants. This type of pipe has good welding properties, but in order to ensure welding quality, correct welding procedures must be followed. At the same time, as needed, preheating and post-weld heat treatment may be required to avoid the occurrence of cold cracks. In addition to the basic black or oiled finish, this pipe can also have other finishes or coatings depending on the customer's needs. During the production process, all pipes must undergo rigorous testing and inspection to ensure their quality and reliability. These tests include dimensional inspection, visual inspection, mechanical testing and non-destructive testing.
Technical Data

Item

12CrMo195 1.7362 DIN17175 alloy steel pipe

Standard

ASTM A213, ASTM A335, JIS G3462, JIS G3458, DIN17175, GB9948, GB 6479, etc.

Material

P1, P2, P12, P11, P22, P5, P9, P91, P92,T1, T2, T11,T12, T5, T9,T22,ST52,

X42, X46, X52, X60,X70,X80,X100, 15CrMo,Cr5Mo,10CrMo910,12Cr2Mo,

13CrMo44,12CrMo195,42CrMo,42CrMO4,x12CrMo91,12CrMo,etc.

Specifications

Wall thickness

1mm~120mm

Outside diameter

6mm~2500mm

Length

5.8m, 6m, 11.8m, 12m, or as required.

Surface

Black painted, PE coated, HDPE, Varnished, Galvanized, etc.

12CrMo195 low alloy structural steel pipe Chemical composition

Grade C≤ Mn P≤ Si≤ S≤ Cr Mo
12CrMo195 0.08~0.05 0.40~0.70 0.035 0.50 0.035 2.00~2.50 0.90~1.20
company advantage
GNEE's annual sales reach US$1 billion, its annual export volume exceeds 50,000 tons, and its products are exported to more than 150 countries around the world. With its excellent quality and efficient service, GNEE Steel Company enjoys a high reputation in domestic and foreign markets.

FAQ

Q.How can I trust you?
A.We think honesty is the core of our company, you can come to know it personally so that you can check our credit.

Q.Can your products be customized?
A.We can make most arades and specifications.meet your different requirement.

Q.Do you have a quality control system?
A.Yes, we have our own quality control laboratory.






Related Products
Service
Certification and testing as per clients need
Third party inspections and approval
Inventory management as per clients
Logistics arrangement for client to help in cost cutting
