EN 10216-2 16Mo3 Alloy Steel Seamless Tubes
EN 10216-2 16Mo3 Alloy Steel Seamless Tubes
EN 10216-2 16Mo3 Alloy Steel Seamless Tubes
EN 10216-2 16Mo3 Alloy Steel Seamless Tubes
EN 10216-2 16Mo3 Alloy Steel Seamless Tubes
EN 10216-2 16Mo3 Alloy Steel Seamless Tubes
EN 10216-2 16Mo3 Alloy Steel Seamless Tubes
EN 10216-2 16Mo3 Alloy Steel Seamless Tubes

EN 10216-2 16Mo3 Alloy Steel Seamless Tubes

EN 10216-2 16Mo3 alloy steel seamless pipe is a high-pressure seamless steel pipe produced in accordance with European standard EN10216-2. This pipe is widely used in petrochemical, power industry and other fields.
standard:EN
Surface :1. Galvanized 2. Black and Color Painting
introduction
Data table
Related Products
Service
Related Projects
Inquiry
introduction
The EN 10216-2 standard produced by GNEE specifies the outer diameter and wall thickness range of 16Mo3 seamless steel pipes. The outer diameter range is from 10.2mm to 711mm, and the wall thickness range is from 1.6mm to 100mm. This range of specifications enables this 16Mo3 Structural seamless pipe to meet the needs of different application scenarios.
The yield strength of EN 10216-2 16Mo3 Alloy Steel pipe is not less than 280 MPa, the tensile strength is between 450-600 MPa, the elongation is not less than 22%, and the impact toughness is not less than 27 J.
Data table

Heat Treatment of  EN 10216-2 16Mo3 Seamless steel pipe

Steel grade Heat
treatment
a
Austenizing Tempering
Steel
name
Steel
number
Temperature °C Cooling
Medium
Temperature °C Cooling
medium
16Mo3 1.5415 +N 890 to 950 Air - -


Chemical composition of EN 10216-2 16Mo3 Seamless alloy boiler tube

Steel grade Steel number C Si Mn P max S max
16Mo3 1.5415 0.12- 0.20 ≤ 0.35 0.40- 0.70 0.025 0.02

EN 10216-2 16Mo3 Seamless steel tubes Details
Manufacture:Seamless process
Wall thickness(WT): 2.1mm--20 mm.
Outer diameter (OD): 21 mm--509mm
Length: 6M or specified length as required.
Ends: Plain End, Beveled End, Treaded
Application
EN10216-2 16Mo3 low alloy structural tube are are used for high temperature service applications in oil refinery piping, steam pipeline, and power plant projects, etc.Payment Terms:T / T, LC
Delivery: 7-15 days after payment
Package: Bundles (hexagonal),Wooden Boxes,Crates (steel/wooden) or as required

company advantage

Why choose GNEE  16Mo3 alloy tube

GNEE is a supplier and exporter of high quality EN 10216-2 alloy steel seamless pipes.
GNEE offers seamless pipes in different sizes, grades, thicknesses and specifications required by its customers. We also provide customers with market competitive prices.
If you are looking for 16Mo3 seamless pipe, please contact us in time to get a quote!



FAQ
Q.Is hot rolled pipe seamless?
A.Hot-rolled pipes are pipe fittings produced through hot-rolling processes and are common mechanical structural parts.
Q.What services do you provide?
A.Customized service for each customer, please feel free to contact us!
Q.Do you have quality control?
A.Yes, we have got BV.SGS certification.
