A53 Grade B Black Carbon Steel Pipe
A53 Grade B Black Carbon Steel Pipe
A53 Grade B Black Carbon Steel Pipe
A53 Grade B Black Carbon Steel Pipe
A53 Grade B Black Carbon Steel Pipe
A53 Grade B Black Carbon Steel Pipe
A53 Grade B Black Carbon Steel Pipe
A53 Grade B Black Carbon Steel Pipe

A53 Grade B Black Carbon Steel Pipe

ASTM A53 Grade B is a standard specification established by ASTM (American Society for Testing and Materials) for black carbon steel pipes.
standard:ASTM
Surface :1. Galvanized 2. Black and Color Painting
introduction
Data table
Related Products
Service
Related Projects
Inquiry
introduction
ASTM A53 Class B pipe can be produced by the seamless or electric resistance welding (ERW) process. The choice between seamless and welded depends on the specific requirements of the application.
A53 steel carbon pipe provided by GNEE
ASTM A53 seamless steel pipe is available in a variety of standard sizes, with nominal pipe sizes ranging from 1/8 inch to 26 inches, to meet the needs of a variety of projects. The wall thickness varies according to different table numbers, such as table 20, table 40, table 80, etc. Each table number corresponds to different wall thickness specifications.
In addition to the standard black or hot-dip galvanized coating, A53 seamless carbon steel pipes can also be specially coated according to customer needs, such as providing other specified coatings. The end processing methods are various, it can be a flat end, or it can be customized into a threaded or beveled form as required. 10% lower price compared to stockists and suppliers in Mumbai and high quality material with manufacturer factory test certificate.
Data table

Tensile Requirements for ASTM A53 Grade B Seamless Pipes

  Seamless and Electric-resistance-weldeD Continuous-WeldeD
  Grade A Grade B
Tensile Strength, min., psi 48,000 60,000 45,000
Yield Strength, min., psi 30,000 35,000 25,000

Mechanical Tests Specified for ASTM A53 Grade B Pipes
Tensile Test - Transverse required on ERW for NPS 8 and large. Sending Test (Cold) - STD and XS-NPS 2 and under XXS-NPS 1 1/4 and under.

  Degree of BenD   Diameter of Mandrel
For Normal A53 Uses 90   12 x nom dia. of pipe
For Close Coiling 180   8 x nom dia. of pipe
company advantage

ASTM A53 Grade B Carbon Steel Pipe Export Market

Gnee is a leading A53 gr b pipe stocker, distributor and supplier in China. With more than 16 years of experience, we have an in-depth understanding of the steel pipe industry. Can implement GB, ASTM, JIS, DIN and other standards. Exported to more than 60 countries and regions including Russia, Canada, India, Brazil, and Southeast Asia.



FAQ
Q.What is A53 B pipe made of?
A.ASTM A53 Grade B carbon steel pipes are built with a combination of chromium oxide and molybdenum. This grade of alloy pipes is used commercially, with other grades as per its applications.
Q.What is the pressure rating for ASTM A53 pipe?
A.Maximum allowable pressure is calculated with the Barlow's formula for A53 Grade B Seamless and Welded Standard Steel Pipe with Yield Strength 35000 psi and design factor 0.7.
