Stainless Steel 304: It contains around 18% chromium and 8% nickel, making it one of the most widely used stainless steel grades. It also contains a small amount of carbon, typically around 0.08%.
standard:ASTM
shape:Round/Rectangle
introduction
Technical Data
Related Products
Service
Related Projects
Inquiry
introduction
304H is an austenitic alloy mainly composed of chromium, nickel and carbon. This alloy has excellent corrosion resistance and high temperature properties, with a minimum yield strength of 205 MPa, which means it retains its shape and structure even when subjected to high stresses. The minimum tensile strength is 515 MPa, which means it has a strong ability to resist tensile deformation. It can easily expand up to 40% as needed, which makes it highly flexible when it comes to withstanding stress and deformation. It has good high temperature resistance and can withstand high temperatures from 500°C to 800°C.
According to ASTM A312 TP standard, 304H seamless pipe shows a high degree of corrosion resistance in various corrosive environments. These tubes are made of titanium and are very strong and durable. ASME SA 312 304H steel pipe is manufactured by longitudinal welding with or without weld seams. The tubes are available in outer diameters ranging from 6.35 mm to 114.3 mm, thicknesses ranging from 0.8 mm to 12.7 mm, and lengths up to 26 meters.
304H stainless steel pipe is an extremely strong, flexible and corrosion-resistant pipe suitable for a variety of applications that need to withstand high temperatures and corrosive environments.
Technical Data

Chemical Composition

  C MN SI P S CR NI N
304 0.07max 2.0max 0.75max 0.045max 0.03max min: 18.0 max: 20.0 min: 8.0 max: 10.5
304H min: 18.0
max:20.0
min: 8.0
max: 10.5
min: 0.04
max:0.10
0.75
max
2.0
max
0.045
max
0.03
max
0.10
max

Mechanical Properties

Grade Tensile Strength ksi (min) Yield Strength 0.2% ksi (min) Elongation % Hardness (Brinell) MAX Hardness (Rockwell B) MAX
304 75 30 40 201 92
304H 75 30 40 201 92

Physical Properties

SS 304
Density
lbm/in3
Thermal Conductivity
(BTU/h ft. °F)
Electrical
Resistivity
(in x 10-6)
Modulus of
Elasticity
(psi x 106
Coefficient of
Thermal Expansion
(in/in)/
°F x 10-6
Specific Heat
(BTU/lb/
°F)
Melting
Range
(°F)
at 68°F: 0.285 9.4 at 212°F 28.3 at 68°F 28 9.4 at 32 – 212°F 0.1200 at 68°F to 212°F 2500 to 2590
  12.4 at 932 °F 39.4 at 752°F   10.2 at 32 – 1000°F
    49.6 at 1652 °F   10.4 at 32 – 1500°F
SS 304H
Denstiy
lbm/in3
Coefficient of
Thermal Expansion (min/in)-°F
Thermal Conductivity BTU/hr-ft-°F Specific Heat BTU/lbm -°F Modules of Elasticity (annealed)2-psi
at 68 °F at 68 – 212°F at 68 – 1600°F at 212°F at 932°F at 32 – 212°F in tension (E)
0.285 9.2 11.0 9.4 12.4 0.12 29 x 106
