ASTM A252 Steel Piling Pipe
ASTM A252 Steel Piling Pipe
ASTM A252 Steel Piling Pipe
ASTM A252 Steel Piling Pipe
ASTM A252 Steel Piling Pipe
ASTM A252 Steel Piling Pipe
ASTM A252 Steel Piling Pipe
ASTM A252 Steel Piling Pipe

ASTM A252 Steel Piling Pipe

ASTM A252 is a standard specification developed by ASTM International for welded and seamless steel piling pipes. These pipes are mainly used for deep foundations to support buildings, bridges and other structures.
standard:ASTM
Surface :1. Galvanized 2. Black and Color Painting
introduction
Data table
Related Products
Service
Related Projects
Inquiry
introduction
ASTM A252 pipe can be manufactured by a variety of production processes, including seamless or welded methods. Welded pipes are usually produced by methods such as resistance welding (ERW), submerged arc welding (SAW) or double submerged arc welding (DSAW).
Material composition:
ASTM A252 piling pipe is usually made of carbon steel. Requirements for chemical composition are specified in the standard to ensure required properties such as strength and durability.
grade:
ASTM A252 submerged arc welded steel pipe is divided into three grades based on its mechanical properties: Grade 1, Grade 2 and Grade 3. These grades are primarily based on two key mechanical properties: tensile strength and yield strength. In piling applications, these properties are particularly important as they directly affect the strength and durability of the pipe.
Although Grade 1 steel pipe has the lowest yield strength and tensile strength, ASTM A252 Grade 3 double submerged arc welding exhibits superior mechanical properties that are significantly better than the other two grades. Its tensile strength is as high as about 456 MPa, and its yield strength is also about 310 MPa. These high strength properties make Grade 3 steel pipes ideal for piling operations where strong structural requirements are required.
Data table

ASTM A252 Steel Pipe Pile Chemical Composition:

Composition, %

C, max Si, max Mn, max P, max S, max

Grade 1

0.26

0.45 1.6 0.05 0.03
Grade 2 0.26 0.45 1.6 0.05 0.03
Grade 3 0.26 0.45 1.6 0.05 0.03

The steel shall contain no more than 0.050% phosphorous.

ASTM A252 Piling Pipe Mechanical properties:

Mechanical Property

Grade 1

Grade 2

Grade 3

Minimum Yield strength ReH MPa

205

240

310

Tensile strength Rm MPa

345

415

455

Minimum elongation A %

30

25

20

Grade: 1, 2, 3 Standard: ASTM A252 Grade: 1, 2, 3
OD: NPS 6" - 56" (168.3 - 1422mm)
WT: 0.134" - 2" (3.40 - 50.8mm)
Length: 6 - 32m

company advantage
Gnee Steel Company is a professional steel company integrating R&D, manufacturing, sales and service. With annual sales of nearly US$1 billion and annual export volume of more than 50,000 tons, it is a steel mill located in Anyang City, Henan Province with convenient transportation. The factory covers an area of about 35,000 square meters, the company has more than 200 employees, and exports to 150 countries every year.

FAQ
1.Q.Why choose Gnee?
A.With us, you will get the most competitive price, guaranteed quality, guaranteed delivery and after-sales service.
2.Q.Can your products be customized?
A.Yes, we can produce and process according to your requirements.
3.Q.What do your factory do regarding quality control?
A: We have obtained ISO, CE and other certifications. From materials to products, we checkevery process to maintain good quality.
