ASTM A335 P92 seamless ferritic alloy steel pipe is a seamless ferritic alloy steel pipe produced according to ASTM A335 standard, also known as T92 seamless steel pipe.
standard:ASTM
Surface :1. Galvanized 2. Black and Color Painting
introduction
Technical Data
Related Products
Service
Related Projects
Inquiry
introduction
ASTM standard A335M P92 is a hot-rolled alloy steel pipe with high temperature strength and heat resistance. This standard steel pipe is suitable for pipes and equipment used under high temperature and high pressure.
ASTM A335 P92 alloy steel seamless pipe chemical composition includes 0.07–0.13 maximum carbon, 0.30 – 0.60 maximum manganese, 0.02 maximum phosphorus, 0.01 sulfur, 0.50 silicon, 8.50–9.50 chromium, and maximum 0.30 – 0.60 molybdenum.
Manufacturing process of ASTM standard A335M P92 alloy steel pipe A335M P92 steel pipe is manufactured by hot rolling process, generally using grate heat treatment method. During the manufacturing process, the temperature and cooling rate of the steel pipe need to be controlled to ensure the structure and performance of the steel pipe.
A335M P92 boiler steel pipe is commonly used in pipelines and equipment under high temperature and pressure, such as burners, boilers, heat exchangers, etc. It has also been widely used in petroleum, chemical industry, electric power, nuclear energy and other fields.
Technical Data

ASTM A335 P92 Seamless Alloy Steel Pipe Chemical Composition(%)

Grade C Mn P S Si Cr Mo V N Ni Al Nb W B
A335 P92 0.07-0.13 0.3-0.6 ≤0.02 ≤0.01 ≤0.5 8.5-9.5 00.3-0.6 0.15-0.25 0.03-0.07 ≤0.4 ≤0.04 0.04-0.09 1.5-2.0 0.001-0.006

ASTM A335 P92 Alloy Steel Pipe Mechanical & Physical Properties

Tensile Strength(MPa) Yield Strength(MPa) Elongation(%)
≥620 ≥440 ≥20

Size Tolerances of ASTM A335 P92 Alloy Steel Pipe

ASTM A530,ASTM A335 NPS Outside Diameter(inch) Tolerance(mm)
1/8≤OD≤1-1/2 ±0.40
1-1/2<OD≤4 ±0.79
4<OD≤8 +1.59 / -0.79
8<OD≤12 +2.38 / -0.79
12<OD ±1%
company advantage
gnee specializes in the research and development, production and sales of seamless steel pipes. We can provide the standards, specifications, materials, applications of carbon steel pipes, alloy steel pipes and their processed products required by customers.

FAQ

What is the ASTM equivalent of A335?
Also known as 1.25Cr-0.5Mo, the UNS designation of ASTM A335 P11 is K11597. Its ASTM equivalent includes ASTM A369 FP11 as well as ASTM A213 T11.

Q.Do you have MOQ?
A.Depends on different ideas, Can be negotiated.The larger the quantity is, the competitive the unit price will be.

Q.Can your products be customized?
A.We can make most arades and specifications.meet your different requirement.
