ASTM A213 T91 T12 T11 Alloy Tube
ASTM A213 T91 T12 T11 Alloy Tube
ASTM A213 T91 T12 T11 Alloy Tube
ASTM A213 T91 T12 T11 Alloy Tube
ASTM A213 T91 T12 T11 Alloy Tube
ASTM A213 T91 T12 T11 Alloy Tube
ASTM A213 T91 T12 T11 Alloy Tube
ASTM A213 T91 T12 T11 Alloy Tube

ASTM A213 T91 T12 T11 Alloy Tube

ASTM A213 T91, T12, T11 alloy pipe is a ferritic and austenitic alloy steel seamless steel pipe used in boilers, superheaters and heat exchangers.
standard:ASTM
Surface :1. Galvanized 2. Black and Color Painting
introduction
Technical Data
Related Products
Service
Related Projects
Inquiry
introduction
ASTM A213 T91, T12, T11 alloy pipe is a ferritic and austenitic alloy steel seamless steel pipe used in boilers, superheaters and heat exchangers.
T91 alloy boiler tubes are mainly used for heating surface tubes of low and medium pressure boilers (working pressure is generally not greater than 5.88Mpa, working temperature is below 450℃); used in high-pressure boilers (working pressure is generally above 9.8Mpa, working temperature is below 450℃ ~650℃ heating surface pipes, economizers, superheaters, reheaters, petrochemical industry pipes, etc.
Technical Data

ASTM A213/ASME SA213 pipe Chemical Composition and Mechanical Properties

Grade Chemical Composition%
C Si Mn P, S Max Cr Mo Ni Max V Al Max
T11 0.05~0.15 0.50~1.00 0.30~0.60 0.025 1.00~1.50 0.44~0.65 - - -
T12 0.05~0.15 Max 0.5 0.30~0.61 0.025 0.80~1.25 0.44~0.65 - - -
T91 0.07~0.14 0.20~0.50 0.30~0.60 0.02 8.0~9.5 0.85~1.05 0.4 0.18~0.25 0.015
Grade Chemical Composition% Mechanical Properties
W B Nb N T. S Y. P Elongation Hardness
T11 - - - - ≥ 415MPa ≥ 205MPa ≥ 30% 163HBW(85HRB)
T12 - - - - ≥ 415MPa ≥ 220MPa ≥ 30% 163HBW(85HRB)
T91 - - 0.06~0.10 0.03~0.07 ≥ 585MPa ≥ 415MPa ≥ 20% 250HBW(25HRB)

ASME SA213  Alloy Steel Seamless Tube Dimensions Tolerance

Outside Diameter OD Tolerance WT Tolerance Ovality Tolerance Cut Length Tolerance
OD≤ 12, 7 mm ± 0, 13 mm ± 15 % - + 3, 18 mm, - 0 mm
12, 7 mm < OD ≤ 38, 1 mm ± 0, 13 mm ± 10 % max, 1, 65 mm + 3, 18 mm, - 0 mm
38, 1 mm < OD ≤ 88, 9 mm ± 0, 25 mm ± 10 % max, 2, 41 mm + 4, 76 mm, - 0 mm
company advantage
GneeGroup was invited to participate in the NECC exhibition in Nam Ci Lien District, Hanoi City, Vietnam. Vietnam is an important market for us. At the exhibition, we actively introduce our company strength, our products and our services to our customers, and conduct in-depth communication and cooperation with our customers.


FAQ

1.Q.What's your advantage?
A.Honest business with competitive price and professional service on export process.

2. Q: What services do you provide?
A: Customized service for each customer, please feel free to contact us!

3.Q.Do you have quality control?
A.Yes, we have got BV.SGS certification.
