A334 Gr1 Gr3 Gr6 Seamless Alloy Pipe
A334 Gr1 Gr3 Gr6 Seamless Alloy Pipe
A334 Gr1 Gr3 Gr6 Seamless Alloy Pipe
A334 Gr1 Gr3 Gr6 Seamless Alloy Pipe
A334 Gr1 Gr3 Gr6 Seamless Alloy Pipe
A334 Gr1 Gr3 Gr6 Seamless Alloy Pipe
A334 Gr1 Gr3 Gr6 Seamless Alloy Pipe
A334 Gr1 Gr3 Gr6 Seamless Alloy Pipe

ASTM A334 Seamless Carbon Steel Pipe

ASTM A334 is a forged seamless carbon steel pipe that is one of the standard specifications for cryogenic applications.
standard:ASTM
Surface :1. Galvanized 2. Black and Color Painting
introduction
Data table
Related Products
Service
Related Projects
Inquiry
introduction

ASTM A334 carbon steel pipe is a specially designed alloy steel pipe with added elements of manganese, molybdenum and silicon to significantly increase its strength and durability. This steel pipe also has excellent corrosion resistance, improves performance after heat treatment, and has excellent weldability.
According to different application requirements, ASTM A334 seamless carbon steel pipes are divided into multiple grades, including Grade 1, Grade 3, Grade 4, Grade 6, Grade 7, Grade 8 and Grade 9. Each grade is designed to meet its specific pressure vessel requirements to meet different temperature ranges.
A334carbon steel round tube performs well in yield strength, its value is not less than 345N/mm^2. In terms of tensile properties, its elongation A reached 21%, showing good plasticity.
As a low temperature seamless steel pipe, A334low temp carbon steel pipe is normalized or normalized and tempered to optimize its performance. This kind of steel pipe is usually presented in this condition when delivered, ensuring its stability and reliability in low temperature environments.
Data table

ASTM A334 Carbon Steel Tube Stock Size Range

Grade ASTM A334 Carbon Steel
Size 1/2" NB to 36" NB
Standard ASTM A334, ASME SA334
Outer Diameter Size 1/4"NB To 2"NB
Wall Thickness 1 mm to 8 mm
Form Round, Square, Rectangular, Hydraulic Etc
Schedule SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Length Single Random, Double Random & Cut Length.
Type Seamless Tube
End Plain End, Beveled End, Treaded

ASME SA / ASTM A334 Low Temperature Pipe Chemical Composition :

C, %

Mn, %

P, %

S, %

0.30 max

0.40-1.06

0.025 max

0.025 max



Tensile Requirements For ASTM A334  Seamless Tubes

Grade Tensile Test MPa or N/mm2 Remaks
(Similar to JIS)
Min Yield point Tensile Strength
Gr. 1 205 380Min Impact Test(J)
2V 18
Gr. 3 240 450Min 2V 18
Gr. 6 240 415Min 2V 18
Gr. 7 240 450Min 2V 18
Gr. 8 520 690Min 2V 18
Gr. 9 315 435Min 2V 18
company advantage
advantages of gnee
1. Passed SGS and ISO9001 certification.
2. Long-term industry experience
3. Management system-internal software
4. Finished product inventory - more than 450 tons.
5. Raw material inventory - more than 700 tons.


FAQ
Q. Why Choose Us?
1. Large scale factory, our production capacity is veryhighcan meet your urgent and large order.
2. The quality of our products is very high, and our group has been doing it for more than 15 years. Good market and feedback from domestic and overseas markets.
Q. How do you guarantee the quality of your products?
A. Each product is produced by certified workshops and inspected piece by piece in accordance with national QA/QC standards, we can also issue quality assurance certificates to our customers.
Q. Can you arrange transportation for us?
A. Yes, we have appointed sea and rail freight forwarders, we can serve our customers with the best price, the best shipment schedule and the best freight rate. We can offer the best price, the fastest shipping schedule and the most professional service professional service.







Related Products
Service
Certification and testing as per clients need
Third party inspections and approval
Inventory management as per clients
Logistics arrangement for client to help in cost cutting
