ASTM A178 Gr.C heat exchanger tubes are widely used in heat exchangers in petroleum, chemical, electric power, metallurgy and other industries. Especially in some medium-low temperature, medium-low pressure heat exchange situations.
standard:ASTM
Surface :1. Galvanized 2. Black and Color Painting
introduction
Data table
Related Products
Service
Related Projects
Inquiry
introduction
ASTM A178 Gr.C Heat Exchanger Tubes are carbon steel and carbon manganese ERW tubes used in boilers, boiler flues, superheaters.
ASTM A178 Gr.C carbon steel pipe main chemical composition content: C: 0.06–0.18% Mn: 0.27–0.63% Pmax: 0.035 Smax: 0.035.
ASTM A178 Gr.C Boiler Tube has high thermal conductivity, good mechanical properties and corrosion resistance. It can operate stably for a long time under high temperature, high pressure and corrosive environment. Widely used in petroleum, chemical, electric power, metallurgy and other industries.
ASTM A178 steel pipe can be used in the temperature range of -46°C to 600°C, and is suitable for petroleum, aerospace, chemical, electric power, boiler, military and other industries.
Data table

Outside diameter and Wall Thickness Tolerance of ASTM A178 Gr.C Heat Exchanger Tube



Outside Diameter tol Wall thickness tol
OD < 50 ±0.05mm S < 4mm ±12.5%
OD > 50 ±1% 4--20mm +15/-12.5%
S≧20mm ±12.5%

Chemical Composition:

Element

Grade C



Medium carbon steel

C%

0.35Max

Mn%

0.80Max

P%

0.035

S%

0.035

Si%

.....

Mechanical Propertise:



Grade C

Tensile Strength loading Ksi (Mpa)

60(415)

Yield Strength Loading Ksi(Mpa)

37(255)

Elongation (50mm)%

=30


Type: Boiler and Heat Exchanger Tube.
Material Grade: ASTM A178 Gr.C.
Size: 48.3 x 2.77mm.
Surface Treatment: Black Painting/Oiled/Coating.
Independence Inspection: Chemical Test, Mechanical Test.
Application: For High Temperature, Heat-Exchanger.
Packing: In Bundles with Steel Strips or as Your Requirements
company advantage
Gnee Steel Pipe Co., Ltd. is an industrial and trading company. We mainly produce and operate carbon steel pipes and alloy steel pipes. Our pipes include liquid delivery pipes, structural pipes, hydraulic strut pipes, boiler pipes and bearing pipes. We typically have over 5,000 tons of pipe in various sizes and standards. Our stock pipe sizes range from 20mm to 406mm outer diameter and 2mm to 70mm wall thickness.


FAQ

1.Q.Why choose Gnee?
A.With us, you will get the most competitive price, guaranteed quality, guaranteed delivery and after-sales service.

2.Q.Do you have quality control?
A.Yes, we have got BV.SGS certification.

3.Q: Can I get some samples?
A: We are glad to provide free samples to you, but we do not offer the freight.
