ASTM A335 P91 Seamless Alloy Pipes
ASTM A335 P91 Seamless Alloy Pipes
ASTM A335 P91 Seamless Alloy Pipes
ASTM A335 P91 Seamless Alloy Pipes
ASTM A335 P91 Seamless Alloy Pipes
ASTM A335 P91 Seamless Alloy Pipes
ASTM A335 P91 Seamless Alloy Pipes
ASTM A335 P91 Seamless Alloy Pipes

ASTM A335 P91 Seamless Alloy Pipes

A335 P91 alloy steel pipe is a high-performance, high-temperature and corrosion-resistant alloy steel pipe, which is widely used in petroleum, chemical industry, electric power and other fields.
standard:ASTM
Surface :1. Galvanized 2. Black and Color Painting
introduction
Data table
Related Products
Service
Related Projects
Inquiry
introduction
A335 P91 alloy pipe is heat-resistant steel with pearlite structure. It has high thermal strength (δb≥440MPa) and oxidation resistance at high temperatures, and has certain hydrogen corrosion resistance.
P91 seamless alloy pipe steel is equivalent to the national standard 10Cr9Mo1VNb. It not only has high oxidation resistance and high temperature steam corrosion resistance, but also has good impact toughness, high and stable long-lasting plasticity and hot strength properties. When the service temperature is lower than 620°C, its allowable stress is higher than that of austenitic stainless steel. Above 550℃, the recommended design allowable stress is about twice that of T9 and 2.25Cr-1Mo steel.
A335 P91 heat-resistant alloy pipe is widely used. It can be used as steel pipes for high-temperature superheaters and reheaters of subcritical and supercritical boilers with wall temperatures <625°C, as well as high-temperature headers and steam pipes with wall temperatures <600°C. It can also be used as furnace tubes for nuclear power heat exchangers and petroleum cracking units.
Data table

Chemical Composition of ASTM A335 P91 Alloy boiler tube

Grade C Mn P S Si Cr
A335 P91 0.08-0.12 0.3-0.6 ≤0.02 ≤0.01 0.2-0.5 8.0-9.5
Mo V N Ni Al Nb
0.85-1.05 0.18-0.25 0.03-0.07 ≤0.4 ≤0.04 0.06-0.10

Mechanical Properties of ASTM A335 P91 Seamless alloy boiler tube

Grade Mechanical property
Tensile Strength(MPa) Yield Strength(MPa) Elongation(%)
P91 ≥510 ≥400 ≥20


The A335 P91 pipe produced by GNEE has a minimum yield strength of 415 MPA and a minimum tensile strength of 585 MPA. The elongation limits for these pipes range from 20 to 30 percent. ASTM A335 GR. P91 pipe gains enhanced creep strength and durability through a heat treatment process in which the metal is normalized at 1500 degrees.

ASTM A335 P91 Seamless Ferritic Alloy Steel Pipe
Manufacturing: Seamless process, hot or cold processing
Wall thickness (WT): 2.1mm-20mm.
Outside diameter (OD): 21 mm - 509 mm
Common specifications: 25mm*7mm, 141.3mm*6.55mm, 323.9mm*25.4mm,
Length: 6M or specified length as required.
End: plain end, bevel end, thread

A335 steel pipe welding precautions
Welding Performance Evaluation of ASTM A335 P91 Steel Pipe
Carbon equivalent is an important indicator for evaluating the welding performance of steel. For alloy steel, other alloying elements also have an important impact on weldability. The carbon equivalent of A335 P91 is calculated as follows:
CEQ=C+Mn/6+(Cr+V+Mo)/5+(Cu+Ni)/15=0.08+0.30/6+(8.0+0.18+0.85)/5 + 0.4 / 15 = 1.9627
Since the calculated carbon equivalent value is much greater than 0.45, this means that the welding performance of A335 P91 is relatively poor.

company advantage
The ASTM A335 P91 grade alloy pipes offered by GNEE are manufactured in accordance with ASTM, ASME and API standards. These pipes are available in wall thicknesses up to 250mm and can be customized upon request. ASTM A335 P91 Alloy Steel Pipe Ends are available with beveled, plain or threaded ends. They are available in single random, fixed length and double random sizes in length. If you have any questions or would like more information about our products or ASTM A335 P91 pipe, please contact us promptly.


FAQ

Q.What is the ASTM A335 P12 equivalent to?
A.ASTM international A335/ ASME SA 335 p12 grade equivalent grades are BSI 3604/620 and their properties are unique and is often called chrome moly pipe because of the composition of Molybdenum and Chromium.Q:What about your price?
A:Our price is very competitive because we are a factory.
Pls feel free to contact us if you are interested in our products.
