ASTM A213 T5 and T5b steel pipe is a seamless ferrite and austenite alloy steel pipe, mainly used in high temperature and high pressure working environment such as boilers, superheaters and heat exchangers.
standard:ASTM
Surface :1. Galvanized 2. Black and Color Painting
introduction
Data table
Related Products
Service
Related Projects
Inquiry
introduction
ASTM A213 T5 and T5b alloy steel pipes are manufactured according to ASTM A213 standards and are seamless ferrite and austenitic alloy steel pipes specifically used in high temperature and high pressure environments such as boilers, superheaters and heat exchangers.
GNEE supplies ASTM A213 /ASME SA213 T5, T5b Seamless alloy tubes made by the seamless process and shall be either hot-finished or cold-finished as specified.
Data table

Chemical Composition of ASTM A213 T5 Seamless Alloy pipe

Grade Chemical Composition(%)
C Mn P S Si Cr Mo
A213 T5 ≤0.15 0.30-0.60 ≤0.025 ≤0.025 ≤0.50 4.00-6.00 0.45-0.65

Mechanical & Physical Properties Of ASTM A213 T5 Seamless Alloy-Steel Tubes

Grade Mechanical property
Tensile Strength(MPa) Yield Strength(MPa) Elongation(%) Hardness(HB)
A213 T5 ≥415 ≥205 30 ≤163

 Specifications of ASME SA 213 Steel Alloy pipe

Specifications ASTM A 213 / ASME SA 213
Size 1/8"NB TO 30"NB IN
Schedule SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS, UPTO 4″ WALL THICK
Length Single Random, Double Random & Required Length, Custom Size – 12 Meter lengths
Form Round, Square, Rectangular, Hydraulic Etc.
Type Seamless
company advantage

Why Choose GNEE ASTM A213 Steel tube

The manufacturing process of ASTM A213 T5 and T5b seamless steel pipes includes raw material preparation, hot rolling, heat treatment, inspection and surface treatment. The raw materials are usually low carbon steel or alloy steel, and the required steel pipe shape and size are formed through a precise rolling process.
The heat treatment process is used to eliminate internal stress and improve the organization and performance of the steel pipe. Finally, the steel pipe will undergo comprehensive testing and surface treatment to ensure that its quality and appearance meet the standard requirements.
In addition, we also provide services such as decoiling, cutting, welding, painting, etc.
If you are looking for seamless tubes, please send us an email!



FAQ

Q.Do you have quality control?
A.Yes, we have got BV.SGS certification.
Q.What is your lead time?
A.Generally, our delivery time is within 7-45 days.
Q:Do you have experience for big projects ?
A:yes , we do .we have good experince for many big project , such as the power plant , Nuclear power station , oil refining project , natural gas project .Abillity to work with big project .








Related Products
Service
Certification and testing as per clients need
Third party inspections and approval
Inventory management as per clients
Logistics arrangement for client to help in cost cutting
