Alloy Steel A213 T1 Tubing

We manufacture these SA213 T1 Seamless Alloy Tubes using the latest technology and the highest quality raw materials. Our tubes made from A213 T1 Material are completely tested and quality approved.
Size range: ½” nominal through 60” OD
Alloy Steel Pipes Specifications & Grades: SA-335 P5, P9, P11, P22, P91, P36 SA-213 T5, T9, T11, T22, T91 A519 4130, 4140/42 Rolled & Welded A-691
Product Introduction
Technical data
Related Products
Service
Related Projects
Inquiry
Product Introduction

T1 Alloy Steel Seamless Tube is alloyed with various elements to improve physical properties and to produce special properties such as resistance to corrosion or heat. T1 Tubing combines carbon steel with other materials such as aluminum, nickel, or copper to fit the specifications of a project. Carbon (C) the most important constituent of T1 Alloy Steel Tube, ASME SA213 T1 Alloy Steel Seamless Tube, SA213 T1 Alloy Steel Seamless Tubing, AS T1 Tubes, T1 Steel Tubes, SA213 gr T1, SA213 grade T1 and SA213 T1 Pipe. ASME SA213 T1 Tubing raises tensile strength, hardness, and resistance to wear and abrasion. It lowers ductility, toughness and machinability in Alloy Steel T1 Seamless Tubing.

T1 Alloy Steel Tube (SA213 T1, Chorme-Moly) is a seamless ferritic Alloy Steel Tube for high temperature service. These T1 material including Alloy Steel T1 Tube and SA213 T1 Seamless Alloy Tube are suitable for high temperature application such as bending, flanging (vanstoning), and similar forming operations, and for fusion welding in the power industry and petro-chemical plants. SA213 T1 Alloy Steel Tubing is also known as ASTM A213 T1 chrome moly tube because of the chemical makeup of Molybdenum (Mo) and Chromium (Cr). Molybdenum maintain the strength of A213 T1 Material as well as the elastic limit, resistance to wear, impact qualities, and hardenability. Moly is the most effective single additive that enhance high temperature creep strength of ASTM A213 T1 Tubes.

Long Lengths ASME SA213 T1 Seamless Tube & High Pressure T1 Boiler Tube are available in hot rolled condition up to 22.5m. Seamless ferritic alloy steel T1 Tube can be supplied to meet special surface requirements and/or close diameter and wall thickness tolerances. Cold-drawn ASTM A213 T1 Alloy Steel Tube are supplied up to 25m with close tolerances, in standard and non-standard dimensions or inside-diameter controlled. We supply all Alloy Steel T1 Tubing & AS T1 Chrome Moly Tubing, such as T1 combustion chamber tubes, T1 heater tube, T1 header tube and T1 line pipe for main steam and reheater circuits, in a complete size range from the smallest dimension up to large heavy wall pipe in all required alloy steel grades.

Size" MSL Make ISMT make JSL Make
1/2" 2,352.94 2,345.59 2,360.29
3/4" 2,132.35 2,125.00 2,139.71
1" 1,985.29 1,977.94 1,992.65
1.25" 1,941.18 1,933.82 1,948.53
1.5" 1,838.24 1,830.88 1,845.59

Please note: All Above Prices are USD $/Ton. All price applicable for SCH 40, SCH 60, SCH 80 & SCH XS T1 Tube.

Technical data

ASTM A213 T1 Tube equivalent

Trade Name

Grade

UNS #

Heater Tubes

1 1/4 Chrome

T11

K11597

A213 / SA213

2 1/4 Chrome

T22

K21590

A213 / SA213

5 Chrome

T5

K41545

A213 / SA213

9 Chrome

T9

K90941

A213 / SA213

T91

T91

K90901

A213 / SA213

T92

T92

K92460

A213 / SA213

Grade C≤ Mn P≤ S≤ Si≤ Mo
T1 0.10~0.20 0.30~0.80 0.025 0.025 0.10~0.50 0.44~0.65

Alloy Steel T1 Tubes Mechanical Properties

Grade Tensile Strength, MPa Yield Strength, MPa Elongation, % Hardness, HB
T1 415 min 205 min 30 min 163 max

Alloy Steel T1 Seamless Tube Outside Diameter and Tolerance

Outside Diameter OD Tolerance WT Tolerance Ovality Tolerance Cut Length Tolerance
OD≤ 12, 7 mm ± 0, 13 mm ± 15 % + 3, 18 mm, – 0 mm
12, 7 mm < OD ≤ 38, 1 mm ± 0, 13 mm ± 10 % max, 1, 65 mm + 3, 18 mm, – 0 mm
38, 1 mm < OD ≤ 88, 9 mm ± 0, 25 mm ± 10 % max, 2, 41 mm + 4, 76 mm, – 0 mm

ASTM A213/ ASME SA213 T1 Alloy Steel Tube Wall thickness & Tolerance

Hot rolled ASTM A213/ ASME SA213 T1 Alloy Steel Tube Outside Diameter, mm Tolerance, %

OD≤101.6, WT≤2.4

+40/-0
OD≤101.6, 2.4<WT≤3.8 +35/-0
OD≤101.6, 3.8<WT≤4.6 +33/-0
OD≤101.6, WT>4.6 +28/-0
OD>101.6, 2.4<WT≤3.8 +35/-0
OD>101.6, 3.8<WT≤4.6 +33/-0
OD>101.6, WT>4.6 +28/-0
Cold Drawn ASTM A213/ ASME SA213 T1 Alloy Steel Tube Outside Diameter, mm Tolerance, %
OD≤38.1 +20/-0
OD>38.1 +22/-0

Length: 5800mm; 6000mm; 6096mm; 11800mm; 12000mm; and so on.
Max length: 16000mm

ASTM A213 T1 Tube Types Out diameter Wall thickness Length
SA213 T1 Seamless Tube (Custom Sizes) 1/2" NB - 60" NB As per requirement Custom
ASTM A213 T1 Welded Tube (in Stock + Custom Sizes) 1/2" NB - 24" NB As per requirement Custom
ASME SA213 T1 Tubing (Custom Sizes) 1/2" NB - 24" NB As per requirement Custom
ASTM A213 High Pressure T1 Boiler Tube 16" NB - 100" NB As per requirement Custom
Standard

SA213 T1 Tube Specification

SA213 T1 Tube Standard ASTM A213 T1, SA213 T1 (with IBR Test Certificate)
SA213 T1 Tube Specifications ASTM A213 & ASTM A209 (T1 , Ta, T1b)
BS/3059/90/PartII/620 & 622
DIN/17175/13CrMo44
DIN/17175/10CrMo910
DIN/17175/15Mo3
SA213 T1 Tube Size 6.35 mm OD to 101.6 mm OD
Sch. & Swg. 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg., 3.6 mm Thk
SA213 T1 Tube Thickness 3-12mm
SA213 T1 Tube Origin European, Japanese, Korean, US, Russian, Indian (Strictly No Chinese Material)
SA213 T1 Tube Tolerance Cold drawn pipe: +/-0.1mm
Cold rolled pipe: +/-0.05mm
Craft Cold rolled and Cold drawn
SA213 T1 Tube Type Seamless / ERW / Welded / Fabricated
SA213 T1 Tube available in Form of Round, Square, Rectangular, Hydraulic Etc.
SA213 T1 Tube Length Standard
Double &
In Cut length also.
SA213 T1 Tube End Plain End, Beveled End, Treaded
Specialized in ASME SA213 T1 Boiler Tube, SA213 T1 Heater Tube, SA213 T1 Heat Exchanger Tube
SA213 gr T1 Additional Testing NACE MR 0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc.
SA213 grade T1 Tube Application Seamless Ferritic Alloy Steel Tube for High-Temperature Service

T1 Alloy Steel Boiler Tubes Applications

T1 alloy steel boiler tubes applications are many and these include refineries, boiling plants, compression stations, process piping, etc. When silicon is added to T1 alloy steel, it increases the performance of the material in high temperature environs of the likes of processing applications, steam lines, etc. Boiler tubes made from T1 alloy steel are used in the manufacturing of reheater tubes, arch tubes, containers, superheaters, airway tubes, coal-saving devices, etc. Rest assured we have loads and loads of experience in producing such types of products, of the highest quality standards, for use in all kinds of applications you have.
