JIS G3454 Carbon Steel Pipe Specification
JIS G3454 Carbon Steel Pipe Specification
JIS G3454 Carbon Steel Pipe Specification
JIS G3454 Carbon Steel Pipe Specification
JIS G3454 Carbon Steel Pipe Specification
JIS G3454 Carbon Steel Pipe Specification
JIS G3454 Carbon Steel Pipe Specification
JIS G3454 Carbon Steel Pipe Specification

JIS G3454 Carbon Steel Pipe Specification

JIS G3456 carbon steel pipe is a type of steel pipe in Japanese Industrial Standard (JIS), mainly used for high temperature pipelines.
standard:JIS
Surface :1. Galvanized 2. Black and Color Painting
introduction
Data table
Related Products
Service
Related Projects
Inquiry
introduction
JIS G3454 carbon steel pipe is used under pressure conditions with a maximum temperature of 350℃.
GNEE's JIS G3454 steel pipe can be made into seamless steel pipe or electric resistance welded steel pipe, and the quality requirements of hot or cold working state can be specified according to the actual needs of customers. Under the JIS G3454 standard, common steel pipe grades include STPG370, STPG410, etc.
Data table

JIS G3454 Seamless Carbon Steel Pipe Specification

Chemical Composition:

Letter symbol of grade Elongation %
C Si Mn P S
STPG 370 0.25 max. 0.35 max. 0.30 to 0.90 0.040 max. 0.040 max.
STPG 410 0.30 max. 0.35 max. 0.30 to 1.00 0.040 max. 0.040 max.

Mechanical Property:

Letter symbol of grade Tensile strength Yield point or proof stress Elongation %
kgf/mm2 {N/mm2} kgf/mm2 {N/mm2} No.11 and No.12 test pieces No. 5 test pieces No. 4 test piece
Longitudinal Transverse Longitudinal Transverse
STPG 370 38 {373}min 22{216} min 30 min 25 min 23 min 28 min
STPG 410 42{412}min 25{245} min 25 min 20 min 19 min 24 min



Grade: JIS G3454 STPG 370/JIS G3454 STPG 410
Outer diameter (size): 1/4-36 inches (13.7-914.4 mm)
Wall thickness: 1.0-30 mm
Length: 1-12 meters or as per customer requirements.
Process: hot rolling, cold drawing

company advantage

Why Choose GNEE

GNEE has 10 hot-rolled seamless steel pipe production lines and 5 cold-drawn seamless steel pipe production lines. It is capable of producing seamless pipes of various specifications and materials. The products are widely used in the fields of petroleum, electric power, chemical industry, coal, machinery, etc.
If you would like to know more about our company or our products, please feel free to contact us.



FAQ

Q.Where are you located? Can I visit you?
A.Sure, you are welcome to visit our factory anytime.
Q.What is your after-sales service?
A.We provide after-sales service and 100% quality assurance for our products.
Q.What is your delivery time?
A.Delivery time is usually about 1 month, if we have stock, we can ship within 7 days.
