BEAM

Standard:GB/T 11263 2010/JIS G3192/ GB/T 707-1988/ BS4-1 1993/ EN10034 1993/ EN 10029/ASTM A6-A6M /JIS G31301/GB/T 33814-2017
Process Type:Hot Rolled, Electric Resistance/High Frequency Welded
End:Square Cut, Plain End, Burr Removed
Product Introduction
Technical Data
Related Products
Service
Related Projects
Inquiry
Product Introduction
Specification:OD:100*100-900*300;WT: 5-34mm; LENGTH: 5.8/6/11.8/12M or 16M max
Standard:GB/T 11263 2010/JIS G3192/ GB/T 707-1988/ BS4-1 1993/ EN10034 1993/ EN 10029/ASTM A6-A6M /JIS G31301/GB/T 33814-2017
Process Type:Hot Rolled, Electric Resistance/High Frequency Welded
End:Square Cut, Plain End, Burr Removed
Surface:Bare/Painted/Light Oiled/Galvanized/Zinc Coating/Primering/Powder Coat
Marking:Stenciling/Embossing/Printing or As customer required.
Packing:Bundles with strips, Waterproof Paper Wrapped or as clients requirement.

Description
Model Sectional size/mm Sectional area/cm2 Theoretical weight/(kg/m)
H×B t1 t2 r
HN 175×90 175×90 5 8 10 23.21 18.2
200×100 198×99 4.5 7 13 23.59 18.5
200×100 5.5 8 13 27.57 21.7
250×125 248X124 5 8 13 32.89 25.8
250×125 6 9 13 37.87 29.7
300×150 298X149 5.5 8 16 41.55 32.6
300×150 6.5 9 16 47.53 37.3
350×175 346×174 6 9 16 53.19 41.8
350X175 7 11 16 63.66 50
400×150 400×150 8 13 16 71.12 55.8

 Standard :JIS G3192 ASTM A36 A572 Gr.50
Grade: Q235/SS400  S235JR S355JR
 Size  GB Wight KG/M  JIS WeightKG/M             size  GB WeightKG/M  JIS    WeightKG/M
100*100*6*8 17.20 16.90 400*200*8*13 66.00 65.40
125*125*6.5*9 23.80 23.60 400*150*8*13 55.80 55.20
148*100*6*9 21.40 21.10 400*400*13*21 172.00
150*75*5*7 14.30 14.00 400*408*21*21 197.00
150*150*7*10 31.90 31.10 414*405*18*28 233.00 232.00
175*90*5*8 18.20 18.00 414*202*10*20 94.50 93.90
175*175*7.5*11 40.30 40.40 428*407*20*35 284.00 283.00
194*150*6*9 31.20 29.90 440*300*11*18 124.00 121.00
198*99*4.5*7 18.50 17.80 446*199*8*12 66.70 65.10
200*100*5.5*8 21.70 20.90 450*200*9*14 76.50 74.90
200*200*8*12 50.50 49.90 470*202*11*24 115.20
200*204*12*12 56.70 56.20 482*300*11*15 115.00 111.00
244*175*7*11 44.10 43.60 488*300*11*18 129.00 125.00
248*124*5*8 25.80 25.10 496*199*9*14 79.50 77.90
250*125*6*9 29.70 29.00 500*200*10*16 89.60 88.20
250*250*9*14 72.40 71.80 510*206*16*21 129.00
250*255*14*14 82.20 81.60 512*202*12*22 114.00
294*200*8*12 57.30 55.80 506*201*11*19 103.00 102.00
294*302*12*12 85.00 83.40 582*300*12*17 137.00 133.00
298*149*5.5*8 32.60 32.00 588*300*12*20 151.00 147.00
298*201*9*14 65.90 64.40 594*302*14*23 175.00 170.00
300*150*6.5*9 37.30 36.70 596*199*10*15 95.10 92.50
300*300*10*15 94.50 93.00 600*200*11*17 106.00 103.00
300*305*15*15 106.00 105.00 600*304*16*26 198.00 194.00
338*351*13*13 106.00   606*201*12*20 120.00 118.00
340*250*9*14 79.70 78.10 692*300*13*20 166.00 163.00
344*348*10*16 115.00 113.00 700*300*13*24 185.00 182.00
344*354*16*16 131.00   708*304*15*28 216.00
346*174*6*9 41.80 41.20 792*300*14*22 191.00 188.00
350*175*7*11 50.00 49.40 800*300*14*26 210.00 207.00
350*350*12*19 137.00 135.00 900*300*16*28 243.00 240.00
350*357*19*19 156.00
388*402*15*15 141.00 140.00
390*300*10*16 107.00 105.00
394*398*11*18 147.00 147.00
394*405*18*18 169.00
396*199*7*11 56.70 56.10
Technical Data
Technical reference
Steel Grade Chemical Composition
C Si Mn P S
Q235B ≤0.20 ≤0.35 ≤1.40 ≤0.045 ≤0.045
Q355B ≤0.24 0.55 ≤1.60 ≤0.035 ≤0.035
SS400B 0.15-0.19 0.20-0.35 0.40-0.55 ≤0.030 ≤0.020

Steel Grade Yield Strength  (N/mm2) Tensile Strength   (N/mm2) Elongation After Fracture  (%)
Q235B ≥235 370-500 ≥26
Q355B ≥355 450-630 ≥21
SS400B ≥245 400-510 ≥17

Process
Packing
Packaging Standard seaworthy export packing,Waterproof paper, and steel strip packed, other types of packing can be customized as every requirement.
Shipping packaging Bundled with firm steel straps, easy for loading and unloading.

Related Products
Service
Certification and testing as per clients need
Third party inspections and approval
Inventory management as per clients
Logistics arrangement for client to help in cost cutting
