COLD DRAWN SEAMLESS PIPE
Cold drawn seamless tubing possesses a high strength-to-weight ratio and can be processed to provide a combination of desired characteristics.
ASTM A106 Carbon Steel Pipe Detailed Specification
| Standard | ASTM A106/A106M |
| Grade | A, B, or C |
| Type | Seamless |
| Material | Carbon Steel |
| Outer Diameter (OD) | Range specified (e.g., 21.3mm - 762mm) |
| Wall Thickness | Range specified (e.g., 3.0mm - 140mm) |
| Length | Specified or cut to length |
| Finish | Smooth, free from defects |
| End Finish | Plain ends, beveled ends, threaded ends (as specified) |
| Packaging | Bundles, wooden boxes, or as per customer requirements |
Chemical Properties of ASTM SA/A106 Steel Pipe
| Grade | C, max. | Mn | P, max. | S, max. | Si, min. | Cr, max. | Cu, max. | Mo, max. | Ni, max. | V, max. |
|---|---|---|---|---|---|---|---|---|---|---|
| Grade B | 0.30 | 0.29 - 1.06 | 0.035 | 0.035 | 0.10 | 0.40 | 0.40 | 0.15 | 0.40 | 0.08 |
| Grade C | 0.35 | 0.28 - 1.06 | 0.035 | 0.035 | 0.10 | 0.40 | 0.40 | 0.15 | 0.40 | 0.08 |
Mechanical Properties of A106 sch 40 carbon steel pipe
| Properties | Grade B | Grade C | |
|---|---|---|---|
| Tensile Strength, min., psi, (MPa) | 60,000 (415) | 70,000 (485) | |
| Yield Strength, min., psi, (MPa) | 35,000 (240) | 40,000 (275) | |
