ASTM A53/A106 SEAMLESS PIPE
A106 SEAMLESS PIPE
ASTM A53 SEAMLESS PIPE
A53 PIPE
ASTM A53/A106 SEAMLESS PIPE
A106 SEAMLESS PIPE
ASTM A53 SEAMLESS PIPE
A53 PIPE

ASTM A53/A106 SEAMLESS PIPE

ASTM A106 seamless steel pipe covers seamless carbon steel nominal wall pipe for high-temperature service, suitable for bending, flanging and similar forming operations.
Size:Out diameter 21.3 - 610 mm Wall thickness 2 - 50 mm
Delivery:Within 30 days and Depends on your order quantity
Product introduction
Technical data
Related Products
Service
Related Projects
Inquiry
Product introduction
Keywords(pipe type):carbon steel pipe,Seamless Steel Pipe, Seamless Stainless Steel Pipe, Steel Pipng,ASTM A53/A106 Seamless Pipe
Size:Out diameter 21.3 - 610 mm Wall thickness 2 - 50 mm
Standard & Grade:ABS 1387, BS EN 10297, BS 4568, BS EN10217, JIS G3457,10#-45#, Cr-Mo alloy, 15NiCuMoNb5, 10Cr9Mo1VNb, A53-A369
Ends:Square Ends/Plain Ends (straight cut, saw cut, torch cut), Beveled/Threaded Ends
Delivery:Within 30 days and Depends on your order quantity
Payment:TT, LC , OA , D/P
Packing:Bundle or bulk , seaworthy packing or for the client's requirement
Usage:Using for machining. It is used in a wide range of applications, including but not limited to refineries, compressor stations, natural gas transmission, steam conduction, and generator plants.
Description
ASTM A53 carbon steel pipe covers seamless, welded, black, and hot-dipped galvanized pipe.
Standard BS 1387, BS EN 10297, BS 4568, BS EN10217, JIS G3457
Grade 10#-45#, Cr-Mo alloy, 15NiCuMoNb5, 10Cr9Mo1VNb, A53-A369
Out diameter 21.3 - 610 mm
Wall thickness 2 - 50 mm
Section Shape Round
Application Fluid Pipe
Surface Treatment varnished,cap,marking
Certification API
Carbon Steel Pipe ASTM A53/106/API 5L B
ST37/ST44 Precision Seamless Steel Pipe DIN 2448/2391/1629/17100
DIN 2391/2448/1629,ST37/ST52 steel pipe ST37/ST52
Hot Rolled Seamless Steel Pipe ASTM A 53/106/API 5L B
Cold Drawn Seamless Steel Boiler Tube ASTM A106/DIN 17175/2448
Carbon Seamless Steel Pipe ASTM A53/106/API 5L B

Technical data
ASTM A53 carbon steel pipe covers seamless, welded, black, and hot-dipped galvanized pipe.
ASTM A53 GRADE A&B
This specification covers seamless and welded black and hot-dipped galvanized steel pipe in nominal size 1/8” in. To 20 in. Inclusive (3.18mm-660.4mm) with nominal (average) wall thickness .
ASTM A106 GRADES A, B & C
This specification covers seamless carbon steel pipe for high temperature service in nominal size 1/8 in. To 26 in. Inclusive (3.18mm-660.4mm)with nominal (average) wall thickness .
Grade A   Carbon 0.25% max. Manganese 0.27 to 0.93%
Grade B   Carbon 0.30% max. Manganese 0.29 to 1.06%
Grade C   Carbon 0.35% max. Manganese 0.29 to 1.06%
All grades have same values for Sulphur 0.058% max. Phosphorus 0.048% max. Silicon 0.20% min.
Standard
Chemical Composition (%):
Standard Grade C Si Mn P S Ni Cr Cu Mo V
ASTM A53M A =0.25 - =0.95 =0.05 =0.045 =0.40 =0.40 =0.40 =0.15 =0.08
B =0.30 - =1.2 =0.05 =0.045 =0.40 =0.40 =0.40 =0.15 =0.08

Mechanical Properties:
Standard Grade Tensile strength  (Mpa) Yield strength  (Mpa) Elongation (%)
ASTM A53M A =330 =205 See table 3 of ASTM A53


Standard Grade C Si Mn P S Ni Cr Cu Mo V
ASTMA106M A =0.25 =0.10 0.27-0.93 =0.035 =0.035 =0.40 =0.40 =0.40 =0.15 =0.08
B =0.30 =0.10 0.29-1.06 =0.035 =0.035 =0.40 =0.40 =0.40 =0.15 =0.08
C =0.35 =0.10 0.29-1.06 =0.035 =0.035 =0.40 =0.40 =0.40 =0.15 =0.08

Mechanical Properties:
Standard Grade Tensile strength  (Mpa) Yield strength  (Mpa) Elongation (%)
ASTM A106M A =330 =205 See table 4 of ASTM A106
B =415 =240
C =485 =275

Painting & Coating
varnished,cap,marking












Related Products
Service
Certification and testing as per clients need
Third party inspections and approval
Inventory management as per clients
Logistics arrangement for client to help in cost cutting
Related Projects
2022-02-22 16:54:38
Thermal power plants
Energy
2022-08-02 10:30:40
Energy
Oil and gas
2022-08-02 10:58:53
Oil and gas
