ASTM A500 LSAW Steel Pipes
ASTM A500 LSAW Steel Pipes
ASTM A500 LSAW Steel Pipes
ASTM A500 LSAW Steel Pipes
ASTM A500 LSAW Steel Pipes
ASTM A500 LSAW Steel Pipes
ASTM A500 LSAW Steel Pipes
ASTM A500 LSAW Steel Pipes

ASTM A500 LSAW Steel Pipes

ASTM A500 straight seam submerged arc welded steel pipe is a straight seam steel pipe manufactured using the submerged arc welding process, and its standard complies with ASTM A500.
standard:ASTM
Surface :1. Galvanized 2. Black and Color Painting
introduction
Technical Data
Related Products
Service
Related Projects
Inquiry
introduction

What is A500 pipe?
ASTM A500 is the standard specification for cold-formed, welded and seamless carbon steel structural tubing. Available in three grades, A through C, it is intended for use in construction and structural applications.

What is the equivalent grade to ASTM A500?
ASTM A500 Gr B welded pipe equivalent material can replace other standard carbon steel pipes due to similar mechanical properties. ASTM A500 Class c pipe is preferred for more demanding applications because of its higher yield and tensile strength.

Longitudinal submerged arc welded steel pipes usually use the JCOE steel pipe forming process, that is, the steel plate undergoes four steps of pre-bending, C forming, O forming and E forming, and is gradually formed into a circular steel pipe. This process can ensure the forming quality and accuracy of steel pipes.
ASTM A500 longitudinal submerged arc welded steel pipes have a wide range of specifications and can produce steel pipes with diameters from 21.3mm to 660mm and wall thicknesses from 2.77mm to 25.4mm.
ASTM A500 submerged arc welded steel pipe is mainly used for structural purposes, such as buildings, bridges, towers, lifting and transportation machinery, ships, industrial furnaces and other fields.

Technical Data

ASTM A500 LSAW steel pipes



Grade B

Grade C

Carbon, Max %

0.260

0.230

Manganese, Max %

----

1.350

Phosphorus, Max %

0.035

0.035

Sulphur, Max %

0.035

0.035

Copper, when copper steel is specified, Min %

0.200

0.200

A500 steel pipe mechanical properties:
(Yield Strength):46,000 psi(315 MPa)
(Tensile Strength):58,000 psi(400 MPa)
(Elongation):23%

company advantage

Why choose us

Gnee Steel Co., Ltd. is a professional steel company integrating R&D, manufacturing, sales and service. The annual export volume is more than 50,000 tons, and the factory covers an area of about 50,000 square meters. The warehouse covers an area of approximately 20,000 square meters.



FAQ

1.Q.What's your advantage?
A.Honest business with competitive price and professional service on export process.

2.Q.Can your products be customized?
A.Yes, we can produce and process according to your requirements.

3.Q. Do you have a quality control system?
A.Yes, we have our own quality control laboratory.








Related Products
Service
Certification and testing as per clients need
Third party inspections and approval
Inventory management as per clients
Logistics arrangement for client to help in cost cutting
