S235JRH grade belongs to standard EN10219. EN10219 S235JRH welded steel pipe is a carbon structural steel, JR means its impact properties are at room temperature.
standard:EN
Surface :1. Galvanized 2. Black and Color Painting
introduction
Data table
Related Products
Service
Related Projects
Inquiry
introduction
EN 10219 S235JRH Carbon Steel Welded Pipe is a welded hollow structural profile of EN 10219 series standard.
The carbon content of S235JRH steel pipe is usually below 0.17%, which makes it have good weldability and machinability. It can absorb external impact force to a certain extent. The yield strength of S235JRH welded steel pipe is usually around 235MPa, and the tensile strength is between 360-510MPa. S235JRH
Welded pipe is mainly used for load-bearing structures such as buildings, houses, civil engineering, etc.
Data table

Chemical composition of EN 10219 S235JRH Tubes

Steel Grade Thickness (mm) C Si Mn P S N CEV
S235JRH 6≤t≤16 ≤0.17 - ≤1.40 ≤0.040 ≤0.040 ≤0.009 ≤0.37
16<t≤40 ≤0.39
40<t≤65 ≤0.20 ≤0.41
65<t≤70 ≤0.44

Mechanical Properties of EN 10219 Carbon Steel Pipes

Steel Grade

Minimum Yield Strength MPa

Tensile Strength MPa

Elongation

Impact Energy

Steel name

Steel number

thickness(mm)

thickness(mm)

% (min)

(KV J) (min)

≤ 16

16> to ≤40

≤3

> 3 ≤40

≤40 mm

test temperature

S235JRH

1.0039

235

225

360-510

360-510

24

20℃

En 10219 S235jrh Cold Formed Pipe Specifications

Grade S235JRH
RHS (Rectangular Hollow Sections) Sizes in mm 10 x 15mm / 150 x50 / 300 x400 / 600 x550
Wall Thickness 0.5 – 25mm
Length 6000-14000 mm
Type Seamless/ Welded / ERW / EFW
company advantage

Why Choose GNEE

GNEE currently has a standing inventory of more than 20,000 tons. We specialize in the production and sales of welded steel pipe products, and have built modern large-scale outdoor warehouses and indoor warehouses. We have different specifications of product stocks and can customize different specifications of products according to your requirements.
Please feel free to contact us for more information!



FAQ
Q: Do you have quality control system?
A: Yes, we have our own quality control laboratory.Third party testing servicesare also available.
Q: What services do you provide?
A: Customized service for each customer, please feel free to contact us!
Q.What is your lead time?
A. Regular stock is usually 10 days. Depends on the products.
