ASME SA 106 Grade A Carbon Steel Pipes for water, gas & sewerage, carbon steel tubes for idlers of belt conveyors, water wells and lancing pipes for various automotive & industrial applications.
Sizes (Seamless): 1/2″ NB – 60″ NB
Wall Thickness available: Schedule 20 – Schedule XXS (heavier on request) up to 250 mm thk.
Product Introduction
Technical data
Related Products
Service
Related Projects
Inquiry
Product Introduction

ASTM A106 Carbon Steel Grade A Pipes are made using high quality raw material and latest technology , which ensures durability, low maintenance and run for long duration. ASME SA 106 Carbon Steel Grade A Tubes are frequently used in light engineering and multiple other industries. We offer ASTM A106 Carbon Steel Grade A Tubes at reasonable price. ASME SA 106 Grade A Carbon Steel Pipes for water, gas & sewerage, carbon steel tubes for idlers of belt conveyors, water wells and lancing pipes for various automotive & industrial applications.

ASTM A106 Grade A Carbon Steel Pipes are designed by our expertise and advanced specialist skilled metallurgists and other technical experts draw on their long experience and in-depth knowledge to deliver optimum and often groundbreaking solutions, within your budget and timescales.
As leading stockholders  of ASME SA 106 Grade A Carbon Steel Tubes and ASTM A106 Grade A Carbon Steel Tubes we focus on your requirements because the end result is as important to us as it is to you. That’s why we add value every step of the way whilst remaining on time and within budget.using high-grade components at our well-equipped infrastructure unit.

Standard Specification of ASME SA 106 Gr. A  Pipes & Tubes :

Specifications ASTM A 106, ASME SA 106
Size Range 1/2” NB to 36” NB
Thickness SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules
Type Seamless / ERW / Welded / Fabricated / CDW
Length Single Random, Double Random & Required Length, Custom Size – 12 Meter lengths
End Connections Plain, Bevel, Screwed, Threaded
Outside Coating Black Painting, Anti-Corrosion Oil, Galvanised Finish, Finish as per customer Requirements



Technical data

Chemical Composition of ASME SA / ASTM A106 GR.A  Carbon Steel Seamless Pipes & Tubes :

Chemical Composition (%)
Grade C(Max) Mn Si(Min) Cu(Max) Ni(Max) Cr(Max) Mo(Max) V(Max) P(Max) S(Max)
A 0.25 0.27~0.93 0.1 0.4 0.4 0.4 0.15 0.08 0.035 0.035



Mechanical properties of A 106 Grade A IBR Pipes and Tubes :

Mechanical Properties:
Grade Tensile Strength (Mpa), Min. Yield Strength (Mpa), Min.
A 330 205



Tolerance of ASTM A106 Grade A Carbon Steel Seamless Pressure Pipes and Tubes :

NPS 1/8″ to 1 1/2″ Over 1 1/2″ to 4″ Over 4″ to 8″ Over 8″ to 18″ Over 18″ to 26″ Over 26″ to 34″ Over 34″ to 48″
OD Tolerance +/- 0.4 +/- 0.8 +1.6, -0.8 +2.4, -0.8 +3.2, -0.8 +4.0, -0.8 +4.8, -0.8
WT Tolerance +/- 12.5%
Weight Tolerance +10%, -3.5%



Standards

OTHER AVAILABLE PRODUCTS OF A106 GRADE A CARBON STEEL PIPE

  • ASTM A 106 Grade A Tubing
  • ASTM A 106 Grade B Pipes
  • ASTM A 106 Gr B Tubes
  • ASTM A 106 Grade B Seamless Tubing Suppliers
  • ASTM A 106 Seamless Line Pipes Manufacturer
  • ASTM A 106 Gr B ERW Pipes Manufacturer
  • ASTM A 106 Gr A ERW Tubing
  • Carbon Steel Seamless Rectangular Pipes Distributors
  • ASTM A 106 Grade B Seamless Square Tubes
  • Carbon Steel Seamless Round Pipes & Tubes
  • ASTM A 106 ERW Pipes Stockiest in China
  • ASTM A 106 Gr A Carbon Steel Seamless Black Round Pipes
  • ASTM A 106 Gr B Welded Pipes
  • ASTM A 106 Gr A Welded Tubes
  • ASTM A106 Welded Pipes & Tubes Dealers
  • A106 Gr B Carbon Steel Capillary Tube
  • A106 GR. A Carbon Steel U Shaped Tubing Stockholder
  • CS Hydraulic Tubes Suppliers
  • ASTM A106 GR. A CS Pipes & Tubes Suppliers
  • A106 Gr B Carbon Steel Welded Tubing

A106 GRADE A CARBON STEEL PIPE PACKAGING
Packing plays very important role for A106 Grade A Carbon Steel Pipe.Different types of packing methods are adopted by GNEE steel, depending on the customer’s need and type of product.Selection of type of packing depends on customers need as specified in customer’s purchase order. If nothing is specified in the customer purchase order, our standard packing style is followed. All shipping documentation is provided for A106 Grade A Carbon Steel Pipe delivery from mill to customer.
All the A106 Grade A Carbon Steel Pipe are supplied with standard end capes on both ends. Special types of end caps are supplied if required by customer.Shipping Marks are attached to each Wooden Crate, Wooden Box and Bundle packing. Every assignment begins with a visit of our experienced sales representative who assesses the volume / weight of the belongings and brief the client about the nature of packing required as well as various documentation formalities when moving from China.











Related Products
Service
Certification and testing as per clients need
Third party inspections and approval
Inventory management as per clients
Logistics arrangement for client to help in cost cutting
