Technical data
ASME SA 106 Grade C Carbon Steel Tubes also offers some other great features such as dimensional accuracy, high performance, easy to use, and more. ASME SA 106 Carbon Steel Grade C Tubes are made by qualitative range of raw materials and are available in a broad spectrum of sizes and materials at most competitive prices. We offer ASME SA 106 Grade C Carbon Steel Pipes in divergent sizes, thicknesses, diameters and specifications to suffice the clients’ piping system requirements.
| Specifications |
: |
ASTM A 106, ASME SA 106 |
| Size Range |
: |
1/2” NB to 36” NB |
| Thickness |
: |
SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules |
| Type |
: |
Seamless / ERW / Welded / Fabricated / CDW |
| Length |
: |
Single Random, Double Random & Required Length, Custom Size – 12 Meter lengths |
| End Connections |
: |
Plain, Bevel, Screwed, Threaded |
| Outside Coating |
: |
Black Painting, Anti-Corrosion Oil, Galvanised Finish, Finish as per customer Requirements |
ASME SA / ASTM A106 GR.C Carbon Steel Seamless Pipes & Tubes Chemical Composition :
| Chemical Composition (%) |
| Grade |
C(Max) |
Mn |
Si(Min) |
Cu(Max) |
Ni(Max) |
Cr(Max) |
Mo(Max) |
V(Max) |
P(Max) |
S(Max) |
| C |
0.35 |
0.29~1.06 |
0.1 |
0.4 |
0.4 |
0.4 |
0.15 |
0.08 |
0.035 |
0.035 |
A 106 Grade C IBR Pipes and Tubes Mechanical properties:
| Mechanical Properties: |
| Grade |
Tensile Strength (Mpa), Min. |
Yield Strength (Mpa), Min. |
| C |
485 |
275 |
Carbon Steel Seamless Pressure Pipes and Tubes Tolerance :
| NPS |
1/8″ to 1 1/2″ |
Over 1 1/2″ to 4″ |
Over 4″ to 8″ |
Over 8″ to 18″ |
Over 18″ to 26″ |
Over 26″ to 34″ |
Over 34″ to 48″ |
| OD Tolerance |
+/- 0.4 |
+/- 0.8 |
+1.6, -0.8 |
+2.4, -0.8 |
+3.2, -0.8 |
+4.0, -0.8 |
+4.8, -0.8 |
| WT Tolerance |
+/- 12.5% |
| Weight Tolerance |
+10%, -3.5% |
