ASTM A589 Carbon Steel Pipe
ASTM A589 covers four specific types of plain end or threaded and coupled carbon steel pipes designed for water well use.
ASTM A333 Grade 6 CS Pipes are made by qualitative range of raw materials and are available in a broad spectrum of sizes and materials at most competitive prices. As these ASME SA 333 Grade6 Carbon Steel Tubes are made available at the most competitive prices, ASTM A333 Grade 6 CS Tubes can be customized in a variety of sizes as per the specifications given by the esteemed patrons.
| Specifications | : | ASTM A 333, ASME SA 333 |
| Size Range | : | 1/2” NB to 36” NB |
| Wall Thickness | : | 2.0mm-14 mm |
| Schedules | : | SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules |
| Type | : | Seamless / Welded |
| Length | : | max 16000mm |
| Outer Dimensions | : | 19.05mm-114.3mm |
| Grade | : | Grade 6 |
| Element |
Grade 6 |
| Carbon, max |
0.3 |
| Manganese |
0.29-1.06 |
| Phosphorous, max |
0.025 |
| Sulfur, max |
0.025 |
| Silicon |
≥0.10 |
| Nickel |
– |
| Grade | Yield strength, min, psi (MPa) | Tensile strength, min, psi (MPa) | Elongation (%) |
| Grade.6 | 35 000 (240) | 60 000 (415) | 30 min |
| Grade | The lowest temperature for strike test | ||||||||
| ℉ | ℃ | ||||||||
| ASTM A333 Gr.6 | -150 | -100 | |||||||
|
Wall Thickness |
Grade 6 |
||
|
in. |
mm |
Longitudinal |
Transverse |
| 5/16 (0.312) |
8 |
30 |
16 |
| 9/32 (.281) |
7.2 |
28 |
15 |
| 1/4 (.250) |
6.4 |
27 |
15 |
| 7/32 (.219) |
5.6 |
26 |
|
| 3/16 (.188) |
4.8 |
24 |
|
| 5/32 (.156) |
4 |
22 |
|
| 1/8 (.125) |
3.2 |
21 |
|
| 3/32 (.094) |
2.4 |
20 |
|
| 1/16 (.063) |
1.6 |
18 |
|
