EN 10083-2 C35 Carbon Steel Seamless Tubes

EN 10083-2 C35 Carbon Steel Seamless Tubes

EN 10083-2 C35 pipe is a pipe made of non-alloy steel material following the European standard EN 10083-2. C35 steel is a medium carbon steel with high strength and toughness.

standard:EN

Surface :1. Galvanized 2. Black and Color Painting

Quote Now

Send E-mail

introduction

‌EN 10083-2 C35 steel pipe is a medium carbon steel with high strength and toughness. The German equivalent of this steel is called CK35 steel.
The chemical composition of C35 seamless steel pipe includes carbon content 0.32-0.39%, silicon content up to 0.40%, manganese content 0.50-0.80%, phosphorus content up to 0.035%, and sulfur content up to 0.035%.
‌EN 10083-2 C35 carbon steel pipe has good heat treatability and welding performance. The required hardness and strength can be obtained through proper heat treatment. ‌It is widely used in mechanical engineering, automobile manufacturing and construction machinery, and is often used to manufacture mechanical parts such as shafts, gears, and wheels.

Data table

EN 10083-2 C35 Carbon Steel Seamless Pipes Equivalent Designation

DIN	EN	BS	NFA	ASTM	ASME
DIN 17204 Grade C35	EN 10083-2 Grade C35	NFA 49-311 Grade TU XC35	ASTM A519 Grade 1035	ASME SA 519 Grade 1035	–

OUTER DIAMETER AND WALL THICKNESS
Execution	Size Range	OD Tolerance	Wall tolerance
Hot-rolled Tube	OD – 80 mmOD > 80 mmWall	± 0.4 mm± 0.5 % of OD	± 0.7 mm± (5 % x wallthickness + 0.1 mm
Hot-rolled peeled tube	All sizesWall	+ 0.25/- 0 mm	± 0.8 mm± (5 % x wall thickness+ 0.2 mm)
Cold Worked tubecold-rolled or cold-drawn	OD 80 Wall Thickness 8	+ 0.30/- 0 mm+ 0.35/- 0 mm+ 0.40/- 0 mm*	± 0.30 mm± 0.35 mm± 0.40 mm

company advantage

Why Choose GNEE

GNEE has an annual output of 600,000 tons. It has a complete and scientific quality certification management system.
For steel series products, there are 16 automatic welding production lines with a monthly output of more than 50,000 tons and 6 galvanizing production lines. We provide high-quality products to customers in different industries and are very popular in overseas markets. Many well-known overseas companies have established long-term business cooperation relationships with us.
If you would like to know more about our company or our products, please feel free to contact us.

FAQ
Q1:Can I get samples before order ?
A1:Yes, of course. Usually our samples are free,
but you need to bear the shipping cost.
Q2:Why should you buy from us not from other suppliers ?
A2:We have our own factory with sufficient quantity,
reasonable price and first-class quality.
